30 April 2015

Late War German Armour: The Hinterhalt (Ambush) Camo Colour Scheme

Hinterhalt Tarnung: Ambush Camo, The Art of Late War German Camouflage

I recently decided to paint some 20mm Panthers, King Tigers and Jagdtigers in Ambush (Hinterhalt) camouflage. As usual, a bit of research followed:


Panthers on the workbench, and progress on Koenigstigers and a Jagdtiger.
Just for the heck of it: Both the Porsche and Henschell turrets.

And of course then we'll need halftracks and scouts in the same scheme, and, and...

East front vs Western Front Pumas

More about the Ambush scheme: There is no German word exactly the equivalent to 'Ambush', hence the variety of terms used to describe the scheme. My paint scheme is loosely based on one of the variants of this scheme, the so-called Dot-Ambush Scheme. On closer research some observers may see some inaccuracies in my work. I call it artistic license.

Collins' German-English Dictionary translates 'ambush' as 'hinterhalt', and is the preferred term in use by modellers for this type of camo.


Hinter (~land) halt literally means 'countryside or land beyond - stop' but the grammatical meaning
(as below) is being closer to 'überfall' (lit. 'overcome, assault from cover or above'). Another term for this type of camouflage was  'licht und schatten tarnung' (lit. 'light and shadow camouflage')

(German: Hinterhalt: Ambush; aus dem Hinterhalt überfallen werden →to be ambushed
in Hinterhalt lockend → Ambushing; lockte in Hinterhalt →ambushed or led into ambush or trap.
See also Dutch or Afrikaans: Hinderlaag )

Panthers, Jagdpanthers, Tiger IIs and Jagdtigers in Hinterhalt Tarnung:

The (short-lived) WW 2 German Hinterhalt or 'Ambush' scheme was at least 4 different paint schemes applied directly to Panther Gs by the MAN and Daimler-Benz factories, between 19th August and 14th September 44 (with zimmerit, on the dark yellow base) and from 14th-30th September (without zimmerit and on the red primer base).

The relatively limited photographic evidence of the use of Hinterhalt had nothing to do with  'popularity' (Tank crews didn't get to choose the colours of their tanks at this stage of the war) but because this was a very short-run scheme. Not a great deal of vehicles from the various factories (Pz.IVs, JgdPz.38s and Tiger IIs,  Jagdpanthers) were painted in this scheme.

On the Panther:

The Panther was born out of a project started in 1938 to replace the Panzer III and Panzer IV tanks. Initial design proposals were made by Krupp, Daimler Benz and MAN. These designs were eventually abandoned (and Krupp dropped out of the competition entirely) as the requirement increased to a vehicle weighing 30 tonnes. This was the  result of encounters with the Soviet T-34 and KV-1 tanks. The T-34 so outclassed the existing models of the Pzkfw III and IV that General Heinz Guderian insisted on a special tank commission to assess the T-34.

Among the features found most desirable by the commission was sloping armour, which gave much improved shot deflection (and also increased the effective armour protection against penetration), wide tracks, (which improved mobility over soft ground), and a heavy caliber high velocity gun (76.2 mm in the case of the T34) ; good armour penetration and the ability to fire high explosive rounds as well as armour piercing.

Daimler-Benz (DB), designer of the successful Panzer III and Stug III, and Maschinenfabrik Augsburg-Nürnberg AG (MAN) were given the task of designing a new 30- to 35-tonne tank. MAN's design was chosen.

About Panzer colours:

Paint Standardization

The paint colors used were defined by the Reichs-Ausshuss für Lieferbedingungen (RAL) (Reich Committee for Terms of Delivery). It is important to note that, while the current Bundeswehr color standard uses some of the same color names, the colors are different from the ones used during the war.

Between 1927 and 1937, German tanks were painted in the Buntfarbenanstrich (colorful paint pattern). The pattern used three colors: RAL Nr. 17 Erdgelb-matt (matte earth yellow), RAL Nr. 18 Braun-matt (matte brown), and RAL Nr. 28 Grün-matt (matte green). The colors were factory sprayed onto the vehicle in the wavy pattern, with a different pattern for each vehicle. The borders were to be either feathered, or bordered by one to three centimeter wide stripes of RAL Nr. 5 Schwarz-matt (matte black).

Early-war, 1937-1940
On 19 July 1937, it was ordered to change the camouflage pattern to Dunkelbraun Nr. 45 (dark brown) and Dunkelgrau Nr. 46 (dark gray), with feathered edges. Vehicles already painted in the Buntfarbenanstrich were not to be painted in the new pattern, unless they were to be re-painted anyway.

On 7 November 1938, it was ordered that all vehicles were to be re-painted by the individual units. At the same time, it was specified that the pattern should be a base coat of Dunkelgrau, with one-third of the vehicle covered in Dunkelbraun.

The dark brown color was very dark, making it very difficult to distinguish the colors on black-and-white photographs. Most photographs therefore appear to show the vehicles painted in a monotone pattern.

Mid-war and North Africa, 1941-1942
After 12 June 1940, units stopped buying paint directly from the suppliers. Instead, paint was issued directly to the units, with Dunkelgrau being the only issued color. On 31 July 1940, to save paint, it was ordered that armor should only be painted Dunkelgrau. On 10 February 1941, the RAL colors were re-numbered, with Dunkelgrau Nr. 46 becoming Dunkelgrau RAL 7021.

On 17 March 1941, it was ordered to paint all vehicles in North Africa a base color of Gelbbraun RAL 8000 (yellow-brown), with one-third of the vehicle covered by Graugrün RAL 7008 (gray-green), with feathered edges. To save paint, the areas covered by Graugrün were not to be covered with the Gelbbraun base color. Small items should only be painted in one color. On 25 March 1942, Gelbbraun and Graugrün were replaced by Braun RAL 8020 (brown) and Grau RAL 7027 (gray), once existing paint stocks were depleted, with no change in pattern.


There are examples of vehicles in Europe in 1941 and 1942 with a two-tone pattern. The most likely explanation is that vehicles intended for North Africa, and painted at the factories, were re-routed to European units.

Mid and Late-war, 1943-1945
On 18 February 1943, all vehicles were ordered to be painted in a base coat of Dunkelgelb RAL 7028 (dark yellow). Only small pieces of equipment were to retain their previous color. On top of the Dunkelgelb base coat, stripes of Rotbraun RAL 8017 (red-brown) and Olivgrün RAL 6003 (olive green) was applied.


The Rotbraun and Olivgrün paint was delivered to the units in tins, which were thinned with any available liquid. It was then applied by the maintenance section, which allowed the pattern to match the terrain. This also resulted in a wide variety of patterns, from elaborate sprayed camouflage, to patterns that look like they were smeared on with a broom and rag.


To standardize and improve camouflage patterns, on 19 August 1944, it was ordered that all vehicles were to be painted at the factory. The pattern, Hinterhalt-Tarnung (ambush camouflage), still used a base color of Dunkelgelb, with Rotbraun and Olivgrün stripes. On top of each color, small dots of the other two were applied. This pattern was created to give the appearance of the sun shining through forest foliage.

Panzers were painted in all dark yellow (lead) oxide (Dunkelgelb)RAL 7028 base colour until 14 Sep 44, when red (iron) oxide primer alone as the base colour was adopted and the use of the anti-magnetic paste, zimmerit, discontinued.

Zimmerit was applied in the factory, and was composed of 40 % Barium sulfate - BaSO4; 25 % polyvinyl acetate – PVA (similar to wood glue); 15 % pigment (ochre); 10 % Zinc sulfide – ZnS and 10 % sawdust. It took several days to dry, and added days to the completion of every vehicle. By the end of the war this delay was unacceptable.

In mid-September 1944, vehicles started leaving the factories in their red oxide primer, with only sparse camouflage. On 31 October 1944, more elaborate camouflage in Dunkelgelb, Rotbraun and Olivgrün began being applied at the factories over the red oxide primer. Furthermore, Dunkelgrau could be used if Dunkelgelb was unavailable. Despite this order, there has never been any photographic evidence that Dunkelgrau was actually used.

On 20 December 1944, it was ordered that a Dunkelgrün base coat, with a hard-edge pattern of Dunkelgelb and Rotbraun should be used.

Confused?

Perhaps the best way to approach late-war panzer camo is to distinguish base coat color from camo pattern. Base colors proceed along one timeline, and camo patterns run on a parallel one. This, along with the wide latitude allowed in interpreting official camo patterns, seems the best way to explain the many variations one sees.


                                         Dunkelgelb (Dark yellow) Panthers for delivery to the front

Dark yellow remained the official basecoat color until October 1944. Assembly plants were then directed to apply camo directly over red oxide primer. There's been much speculation but no real evidence as for the reason for this change. One probability is that  yellow was in short supply due to Allied bombing raids on German industry.The other is that dark yellow became less useful as a camo color as the physical and tactical environments changed in late '44.

Whatever the reason for the shift from yellow to red oxide, it must have been good enough to outweigh the disadvantages of leaving primer exposed to the weather.



USAF colour images of a Panther/Jagdpanther  Factory (Possibly MNH- Hannover) showing  2-3 even 4 different base coats. There is a great deal of speculation on the internet on the exact nature of the colours seen here, ranging from baked enamelling through to wet/part cured paint that caught fire during the raids that destroyed the factories as an explanation for the dark grey base coats.

In December 1944 all component producers were directed to paint major components dark green before shipment to the assembly plants due to the Allied air threat. There apparently wasn't enough dark green for all vehicles, and the green seems to have been prioritized for Tigers, Panthers and Jagdpanzers. Thus everything from Pz IVs down in size, weight and priority often got a dark yellow base coat. It's unclear if dark yellow stocks had been replenished to permit this.

As for camouflage, what's commonly called ambush pattern was first used in August 44, due to allied air supremacy on all fronts, and continual losses of German armour due to air strikes.

 From September 44, there seems to have been at least three official camo patterns, of which two were most widely used. Of these, one was essentially "ambush" pattern, with or without "dots." The second included dark brown areas with dark yellow stripes, which could be straight diagonals or wavy and irregular. While these patterns initially were prescribed for seasonal use, they soon were used on a continuous basis.

It seems that different assembly plants tended to use idiosyncratic versions of one of the patterns on their vehicles. Henschel, Wegmann and the N'werke (MAN Nuremberg) used the ambush pattern, whether on Tiger IIs or Pz IVs, whatever the base color. MAN, MNH, and DB used variants of the striped pattern on Panthers and Jagdpanthers, again without regard to base color.

Vomag generally used ambush, then later irregular stripes on Jgpz IV L/70(V)s, while L/70(A)s seem to have gotten ambush, without dots. Alkett and Krupp-Gruson may not have been issued camo paint to any great extent, because most of their late products seem to appear in plain dark yellow. Camo was applied with sprayer and masks and by brush. It's unclear the extent to which freehand-sprayed patterns were factory products.

It's important to recognize the huge range of variation in camo as it was applied. Paint availability was an obvious factor, but there also were the idiosancracies of each plant, line, foreman or even worker. It's often hard to tell the basecoat color in a camo pattern. Irregular yellow stripes can be very tough to distinguish from narrow areas of yellow base coat under camo. Predominantly B&W photos from the period also lead to guesswork.


Jagdpanthers, clearly receiving the later vertical striped pattern.
Or is it just reflections and shadows from the windows above?

Field units were directed as of  December 1944 (IIRC) to repaint equipment shipped to them not in compliance with painting directives. It's unclear if this meant they were to try to apply the standard patterns in the field, and what they were supposed to use to do so. The reality seems to have been that units with leftover tarn pastern, which were no longer shipped to units, and paint intended for use after repairs, improvised camo as best they could. Many vehicles were left in plain yellow, of course.

Panther schemes:


By September 1944 the Panther G model was in full productionNot many Panther Gs were snow-camouflaged (Again, nothing to do with 'popularity'. Before Jan 45 there was not enough snow on the ground to make it necessary by either side in the conflict)







The Panther G was in the main produced  by MAN, Daimler-Benz, MNH and Demag. Each factory had different zimmerit patterns, balkenkreuz and factory number placement. Factories of origin could sometimes be identified for individual tanks based on these characteristics.

Other Panther tank factories that applied 'ambush' schemes included Niebelungenwerk, Skoda, Henschel, Krupp and possibly others. There was no set single scheme, many factories applied the same painting directive differently. As some patterns appear to have been used by more than one factory, it is likely that at least some of the design masters originated at higher command level, and then sent to the individual factories for their drawing-offices to translate into stencils.

The paint schemes were probably introduced around 19th - 20th August at the Panther factories at MAN and MNH, which accounts for the early examples also having zimmerit.
Krupp also had zimmerit and Disc-camouflage on their late August '44 StuG.IVs, and few early Vomag IV/70s may also have had both.


Brumm Baer with MAN factory applied disc pattern

By mid-September, zimmerit application had been discontinued. In contrast to MAN and MNH, Daimler-Benz and the remaining tank manufacturers may have initiated their schemes after this date, as their patterns only appear on non-zimmeritted vehicles.

However, by early October the 'ambush' patterns were no longer being applied. This was possibly because the system requirements ran contrary to the mid-September 44 directive for 'sparing use' of paint, and likely because it took extra and ill-afforded skilled worker time on the production line.

Surprisingly few photographs of 'ambush' camo vehicles have survived, given the number of factories involved. A good proportion of August and September's Panther production would have been painted in the 'ambush' schemes. Much of August's production was channeled into the newly-formed Panzer Brigades and squandered away during the September battles on the Eastern Front. Relatively few of these vehicles were ever photographed.

There were two official 'ambush' schemes applied to Panthers (This was all new production Panthers, as there was no ' returned-damaged-for-a-repaint-in-ambush-scheme' policy). The scheme was applied by the factories, and not in the field, though some retouching (to repair damage or change tac numbers) probably took place.


Notably one well-photographed MAN Befehlspanther G ('R01' of Hermann Goering PzDiv) had Disc-camouflage applied to its schürzen only, in a slightly different version of the scheme, showing the edges of the discs similar to the Skoda/Krupp patterns. This may have been applied by HG troops, so is possibly an isolated example, or may have been schürzen removed from a damaged or destroyed vehicle.





Disc Pattern Hinterhalt Tarnung:
The first variant is the disc-camouflage or corn chip series of patterns. This was practiced by MAN and MNH on the Panther G. Vomag also used at least one of these patterns on the Panzer IV/70 and even a few final model Panzerjäger 39's (Jagdpanzer IV's).
Uniquely their Disc-camouflage was formed by dunkelgelb and was sprayed through a stencil made from overlapping discs on top of the olivgrun and rotbraun areas only of their standard factory patterns. This differed from the disc-camouflage system used by the other manufacturers as it used purely this application, i.e. the outside edges of the disc areas were not defined, but merely blended into the dunkelgelb. This is in sharp contrast to Krupp's or Skoda's disc-camouflage, for instance, where the outsides of the disc areas are clearly seen.


The system utilised stencils that matched left/right and top/bottom so a seamless pattern was made over the whole vehicle.
MAN produced some of their 19th August - 7th September production run with Disc-camouflage patterns, sprayed onto their vertically-lined rollered zimmerit, (another factory identifying idiosancrasy); then continued until at least end of September without zimmerit.
MNH also produced G's with Disc-camouflage patterns but on their own horizontally troweled zimmerit. A few zimmeritted MNH G's also had the crew heater fan tower (which shouldn't have been fitted till October). Again, MNH continued until at least end of September without zimmerit.

 Around this time they commenced using their trademark diagonal stripe camo patterns, and the final 'ambush' examples may have even had both.






The second pattern was utilized by Daimler-Benz and was formed by spraying small delicate spots of contrasting color onto some or all three base colors. (So-called Dot pattern)




Variants of this utilising lines or triangular shapes have given rise to other, unofficial descriptions:




 Diagonal stripe patterns:



 The rot braun mid-war camo that was probably the precursor to the ambush scheme:





Note the difference in base colour yellow. (Close to Vallejo Middle Stone in these reproduction paint jobs on the Bovington Jagdpanzer and Panthers, and my choice of colour for my models)


Late war striped (disruptive) camo over green base:





 Tiger II or B / Königstiger (Bengal Tiger, not King Tiger as often erroneously translated) :



Showing the early curved Porsche turret, also with zimmerit applied


The later, (and more numerous) more square Henschel turret

 Artists impressions:






And the Sturmtiger:




Jagdpanzer 38(t)


Jagdpanzer 38(t) (often incorrectly known as the Hetzer), in ambush camouflage without dots

The Jagdpanzer 38 (Sd.Kfz. 138/2), was a German light tank destroyer of the Second World War based on a modified Czechoslovakian Panzer 38(t) chassis. The project was inspired by the Romanian "Mareşal" tank destroyer. The name Hetzer was not commonly used for this vehicle in WW2.



"Hetzer" was the designation for a related prototype, the E-10. The Škoda factory confused the two names for a very short period in its documentation and the very first unit equipped with the vehicle thus for a few weeks applied the incorrect name until matters were cleared.

There is a briefing paper from Heinz Guderian to Hitler claiming that an unofficial name, Hetzer, had spontaneously been coined by the troops. Post-war historians basing themselves on this statement made the name popular in their works, though the vehicle was never named as such in official documents or in practice. It was simply known as a Jagdpanzer.

The Jagdpanzer 38 succeeded the open-top Marder III (based on the same chassis) in April 1944; about 2584 were built until the end of the war.

While I am ranting about misconceptions:
One I came across repeatedly while researching this article:

The German WW2 Barred Cross national insignia is called a BALKENKREUZ (kreuz =cross). BALKEN, Not a BALKAN cross. It is a cross made of bars or beams, Balken, in German.
It has nothing to do with the Balkan states.



Wiki: The Balkenkreuz is a straight-armed cross that was the emblem of the Wehrmacht (German Armed Forces) and its branches in World War II. It was used by the Heer (Army), Luftwaffe (Air Force), and Kriegsmarine (Navy).

German:  Balken refers to a wooden beam or girder, yielding a translation of Balkenkreuz as "beam cross" or "bar cross" or "balk cross".The name is often and erroneously rendered as "Balkan Cross" in English.







22 November 2014

The Facts and the FURY: M4A3E8 Sherman

FURY: M4A3E8 Sherman in the movies

I saw “Fury” with my son Luc, and Mark T. and his son Cameron last night. Stopped for a curry at at our favourite restaurant on the way in, and settled in to watch the latest war movie offering at the local cinema.



I thought it was well worth the effort.  A brutal, realistic, violent portrayal of tank warfare, a story not often told. I thought it one of the better movies I've seen focusing on the subject.

“Fury” revolves around the tank crew of a late war M4A3E8 Sherman tank with the name “Fury” crudely painted on the barrel of its 76 mm gun.  The crew is commanded by Staff Sergeant Don “Wardaddy” Collier (Brad Pitt).  The rest of the crew consists of veterans Boyd “Bible” Swan (Shia LaBeouf) the gunner, Grady “Coon-Ass” Travis (Jon Bernthal) the loader, Trini “Gordo” Garcia (Michael Pena) the driver and the very green and sensitive Norman "Eventually to become Machine" Ellison (Logan Lerman), a soldier from the typing pool press-ganged into serving as the bow gunner due to a shortage of trained tank crewmen.

From a historical equipment and military hardware depiction perspective, the movie is great.  Unlike most other war movies I've seen there are relatively few inaccuracies to distract from the movie’s message.

I appreciated the use of  different types of rounds against different targets as well as  personal idiosyncrasies of the lead character carrying a colt six-shooter revolver (A-la Patton, albeit not a pair of pearl handled six-shooters) and a German MP 44 SMG, and also the hypocrisy of looting war medals off dead enemies, displaying them in the tank; and then shooting a German soldier who was wearing a US trench coat in the back. There was several sub-plots that I found quite interesting: History buffs may have picked up on some of them. I may also have missed a few. Later more on that.

The interactions between soldiers, superiors, subordinates, civilians and the enemy come across well, although a bit stereotyped. (Inexperienced and disrespected junior officer sending the platoon off to their doom, and the battle-hardened field commander, "You're all that we have", sorry to send you-in-but-hold-the-line-and-buy-us-time cliches)

Speaking of stereotypes, the director/screenwriter (thankfully) chose not to have the stereotyped African American, Jewish or Italian crew members. No slur intended in saying this, but in some ways I found it refreshing to escape the common Hollywood angst subjects. Instead they opted for a Hispanic, bible punching Episcopalian and a Cajun Swamprat...

German officers were the usual (ho-hum) stereotypes of fanatical Nazis who mindlessly send their troops in to die and kill innocents left right and centre. Even the field officers. Historically this was not the case. Just like the British and Americans, German officers and NCOs led from the front, cared about their men, and even late in the war, and suffered an incredibly high rate of attrition.

The final scene of droves of SS troopers in a suicidal rush attacking a tank with small arms while their officer stands by egging them on, is a little hard to believe. When they were seen marching up they had enough shouldered panzerfausts to make them look like an asparagus field! The officer than later cracks open a packing case, nowhere seen before, and exclaims: "These are the only ones we have"

These were supposedly elite soldiers, well led and trained, and even if inexperienced, their NCOs/officers would not have committed them to a suicide attack while they had perfectly good anti-tank weapons. Against an immobilised Sherman. And not taking cover ? Deploying the MG 42 in the open ?
But I suppose you could pick holes in anything, and the object of the movie is entertainment, and not military accuracy after all.

The German speakers among us also probably picked up that the subtitles were quite often inaccurate to what was being said or written on the placards of the executed civilians, for example. Not that it detracted majorly from the story line, but just saying. (One placard on a strung up woman read: "I would not let my children go to war" and it was subtitled " I would not go to war" and Brad Pitt also read out it incorrectly to his crew. So much for being a German speaker as the movie implies. (Think a little pathos in the script was lost there as a result.)


He also addresses the 20-something young woman as "Maedchen (little girl) where any German speaker would have addressed her as " Fraulein" (Young Lady); as the subtitles this time grammatically correctly read, but did not reflect what he actually said.

The unsung heroes of the movie are the tanks though.  The movie features the only running Pzkfw VI Tiger tank in the world (The Bovington Tiger) and uses several versions of the Sherman which would have been very accurate for the time. In Saving Private Ryan a T-34 was dressed up to vaguely resemble either a Tiger or late model PzKfw IV.

 Unlike in today’s combat units, Allied units did often have mismatched equipment as new vehicles were supplied to replace older models that were destroyed/damaged beyond repair in combat. Older models were retained until they were considered obsolete or unserviceable.  This is noticeable when looking at the American tank platoon that had various models of the M4 Sherman (at least 3 that I could identify without losing the plot of the story by focusing solely on the hardware)




This is historically important, as only the last production model Shermans (Armed with the 76 mm high velocity gun) had any real chance of penetrating most German heavy and medium tanks (Pzkfw V Panther  and Tiger I and II by the end of the war) at a distance. German tanks could engage and destroy Shermans at long range, whilst the standard 75mm rounds failed to penetrate the thick frontal armour of the German tanks. It wasn't uncommon to need a five to one (or more) ratio of Shermans to one Tiger to overwhelm the enemy.

The Bovington Tiger

This is accurately portrayed as the 75 mm guns fail to make any impact on the Tiger and its 88 mm take them out with comparative ease over the same distance. The 76 mm of the Easy 8  also only destroys the tiger at short range, from the rear, and by out-maneuvering it, and then firing 2 shots at point blank range

Click here for a walk-around the Sherman M4A3E8 (Easy Eight) that was used in the filming of Fury

One criticism I would have of the fire-fight scenes is the decision to use laser to depict tracer. The flight paths were inaccurate and it looked a little like star-wars. (But then that was probably a safety decision, but it could just as easily have been done in CGI.)


 If you've ever seen real tracer fire you'll agree it looks nothing like that. The flight path is more parabolic and appeared linear in the shots. Though the US did use blue tracer, it was far more common to use a yellowish red.The only picture I could find (above) shows the red tracer, but the blue was very apparent in the movie.


I enjoyed a the good Hollywood style yarn, never the less.

The Guardian in the UK has the comments from a 91 year old radio operator veteran on the movie:

"Fury accurately portrays how superior the German tanks were. A Sherman provided you with protection against most enemy fire but against a Tiger it could easily become your coffin. I remember a very near miss where an eight cm shell from a Tiger tank went within inches of our turret and we decided not to stay around too long after that. In open combat we never had a chance. So, like in Fury, we always had to be one step ahead. It was only because we could call up air strikes and had many more tanks than the Germans that we eventually won."

As the film makes clear, a Sherman tank was a lightweight in comparison to a Tiger. The Sherman weighed 33 tonnes and had a 75 mm gun, compared to the Tiger's 54 tonnes and a 88 mm gun. A Tiger also had 3.9 inch thick armour, so shells from a Sherman literally bounced off it.

"Fury shows just how vulnerable you were fighting in a Sherman tank. There is a lot of blood and gore in the film but nothing can really come close to the true horrors of tank warfare. I saw people being blown up and burnt alive. Going to see Fury you don't get that dreadful, nauseating smell of burnt flesh. That will stay with me forever."

"I was in the Essex Yeomanry, a territorial regiment. All the crew were from Essex except me. It took us a while to get along but then I trusted them implicitly with my life. We fought along side the Americans in their Sherman tanks and I found them to be very brave. We didn't write the name of our tank on the barrel like they did in Fury or plaster the inside with photographs but we were just as proud of our tank. Ours was called Beverley and her name was written on the turret."

The corpses certainly mount up in Fury, particularly in the final scene. This was the only part Bill,  (the veteran) too, felt lacked credibility.

"I thought the film showed accurately how tough life could be in a tank, but the final scene where the crew hold out against a battalion of Waffen SS troops was too far fetched. The Germans seemed to be used as canon fodder. In reality they would have been battle-hardened and fanatical troops who would have easily taken out an immobile Sherman tank using Panzerfausts (an anti-tank bazooka).

They also seemed to have an inexhaustible supply of ammunition and fuel. A Sherman tank only does five miles to the gallon so I think they would have run out long before the final showdown."



The Easy 8 used in the film as well as the Tiger are now on display at Bovington. Clink on the link for more pictures of both vehicles and the opening of the display: Blackmore Vale Magazine



9 August 2013

Kursk Order of Battle: Protagonists Part 2: The Russians

Kursk Protagonists Part 2: Soviet Forces



Western Front
(Vasily Sokolovsky)


50th Army (Ivan Boldin)
11th Guards Army (Ivan Bagramyan)
1st Air Army (Mikhail Gromov)

Bryansk Front
(Markian Popov)



3rd Army (Alexander Gorbatov)
61st Army (Pavel Belov)
63rd Army (Vladimir Kolpakchi)
15th Air Army (Nikolai Naumenko)


Central Front
(Konstantin Rokossovsky)


13th Army (Nikolay Pukhov)
48th Army (Prokofy Romanenko)
60th Army (Ivan Chernyakhovsky)
65th Army (Pavel Batov)
70th Army (Ivan Galanin)
2nd Tank Army (Alexei Rodin)
16th Air Army (Sergei Rudenko)

Voronezh Front
(Nikolai Vatutin)



6th Guards Army (Ivan Chistiakov)
7th Guards Army (Mikhail Shumilov)
38th Army (Nikandr Chibisov)
40th Army (Kirill Moskalenko)
69th Army (Vasily Kriuchenkin)
1st Tank Army (Mikhail Katukov)
2nd Air Army (Stepan Kravsovsky)


Steppe Front
(Ivan Konev)



5th Guards Army (Alexei Zhadov)
5th Guards Tank Army (Pavel Rotmistrov)
5th Air Army (Sergei Goriunov)

 Composition of forces:

1. Western Front
(Vasily Sokolovsky)

50th Army (Ivan Boldin)


 38th Rifle Corps (Alexei Tereshkov)

17th Rifle Division
326th Rifle Division
413th Rifle Division
49th Rifle Division
64th Rifle Division
212th Rifle Division
324th Rifle Division

11th Guards Army


(Ivan Bagramyan)


8th Guards Rifle Corps
11th Guards Rifle Division
26th Guards Rifle Division
83rd Guards Rifle Division
16th Guards Rifle Corps
1st Guards Rifle Division
16th Guards Rifle Division
31st Guards Rifle Division
169th Rifle Division
36th Guards Rifle Corps
5th Guards Rifle Division
18th Guards Rifle Division
84th Guards Rifle Division
108th Rifle Division
217th Rifle Division

1st Air Army (Mikhail Gromov)


2nd Assault Air Corps
2nd Fighter Air Corps
8th Fighter Air Corps

1st Independent Tank Corps (Vasily Butkov)
5th Independent Tank Corps (Mikhail Sakhno)


2. Bryansk Front (Markian Popov)

3rd Army (Alexander Gorbatov)



41st Rifle Corps (Viktor Urbanovich)
235th Rifle Division
308th Rifle Division
380th Rifle Division
269th Rifle Division
283rd Rifle Division
342nd Rifle Division

61st Army (Pavel Belov)

Portrait of Colonel-General Pavel Alekseevich Belov

9th Guards Rifle Corps (Arkady Boreiko)

12th Guards Rifle Division
76th Guards Rifle Division
77th Guards Rifle Division
97th Rifle Division
110th Rifle Division
336th Rifle Division
356th Rifle Division
415th Rifle Division


63rd Army (Vladimir Kolpakchi)

5th Rifle Division
41st Rifle Division
129th Rifle Division
250th Rifle Division
287th Rifle Division
348th Rifle Division
397th Rifle Division


15th Air Army (Nikolai Naumenko)

1st Guards Fighter Air Corps
3rd Assault Air Corps

 25th Rifle Corps
186th Rifle Division
283rd Rifle Division
362nd Rifle Division


1st Independent Guards Tank Corps

3. Central Front (Konstantin Rokossovsky)

17th Guards Rifle Corps (Andrei Bondarev)
6th Guards Rifle Division
70th Guards Rifle Division
75th Guards Rifle Division

18th Guards Rifle Corps (Ivan Afonin)
2nd Guards Airborne Division
3rd Guards Airborne Division
4th Guards Airborne Division


15th Rifle Corps (Ivan Liudnikov)
8th Rifle Division
74th Rifle Division
148th Rifle Division

29th Rifle Corps (Afanasy Slyshkin)
15th Rifle Division
81st Rifle Division
307th Rifle Division

48th Army (Prokofy Romanenko)


42nd Rifle Corps (Konstantin Kolganov)
16th Rifle Division
202nd Rifle Division
399th Rifle Division
73rd Rifle Division
137th Rifle Division
143rd Rifle Division
170th Rifle Division

60th Army (Ivan Chernyakhovsky)
24th Rifle Corps
42nd Rifle Division
112th Rifle Division
30th Rifle Corps
121st Rifle Division
141st Rifle Division
322nd Rifle Division

Independent 55th Rifle Division

65th Army (Pavel Batov)
18th Rifle Corps
69th Rifle Division
149th Rifle Division
246th Rifle Division
27th Rifle Corps
60th Rifle Division
193rd Rifle Division
37th Guards Rifle Division
181st Rifle Division
194th Rifle Division
354th Rifle Division

70th Army (Ivan Galanin)
28th Rifle Corps (Aleksandr Nechaev)
132nd Rifle Division
211th Rifle Division
280th Rifle Division
102nd Rifle Division
106th Rifle Division
140th Rifle Division
162nd Rifle Division
354th Rifle Division

2nd Tank Army (Alexei Rodin)
3rd Tank Corps
16th Tank Corps


16th Air Army (Sergei Rudenko)
3rd Bombing Air Corps
6th Mixed Air Corps
6th Fighter Air Corps

Independent 9th Tank Corps

Independent 19th Tank Corps

4. Voronezh Front (Nikolai Vatutin)

6th Guards Army (Ivan Chistiakov)
22nd Guards Rifle Corps
67th Guards Rifle Division
71st Guards Rifle Division
90th Guards Rifle Division
23rd Guards Rifle Corps
51st Guards Rifle Division
52nd Guards Rifle Division
375th Rifle Division
Independent 89th Guards Rifle Division

7th Guards Army (Mikhail Shumilov)
24th Guards Rifle Corps (Nikolai Vasilev)
15th Guards Rifle Division
36th Guards Rifle Division
72nd Guards Rifle Division

25th Guards Rifle Corps (Gany Safiulin)
73rd Guards Rifle Division
78th Guards Rifle Division
81st Guards Rifle Division
Independent 213th Rifle Division


38th Army (Nikandr Chibisov)
50th Rifle Corps
167th Rifle Division
232nd Rifle Division
340th Rifle Division
51st Rifle Corps (Petr Avdeenko)
180th Rifle Division
240th Rifle Division
Independent 204th Rifle Division

40th Army (Kirill Moskalenko)
47th Rifle Corps
161st Rifle Division
206th Rifle Division
237th Rifle Division

52nd Rifle Corps (Frants Perkhorovich)
100th Rifle Division
219th Rifle Division
309th Rifle Division
Independent 184th Rifle Division

69th Army (Vasily Kriuchenkin)
48th Rifle Corps (Zinovy Rogozny)
107th Rifle Division
183rd Rifle Division
307th Rifle Division
49th Rifle Corps
111th Rifle Division
270th Rifle Division

1st Tank Army (Mikhail Katukov)
6th Tank Corps (Andrey Getman)
31st Tank Corps
3rd Mechanized Corps

2nd Air Army (Stepan Kravsovsky)
1st Bombing Air Corps
1st Assault Air Corps
4th Fighter Air Corps
5th Fighter Air Corps


35th Guards Rifle Corps
92nd Guards Rifle Division
93rd Guards Rifle Division
94th Guards Rifle Division

Independent 2nd Guards Tank Corps
Independent 3rd Guards Tank Corps

Steppe Front (Ivan Konev)
This order of battle does not show the complete composition of the Steppe Front.
 In addition to the units listed below, there are also
the 4th Guards, 27th, 47th and 53rd Armies.

5th Guards Army (Alexei Zhadov)
32nd Guards Rifle Corps (Aleksandr Rodimtsev)
13th Guards Rifle Division
66th Guards Rifle Division
6th Airborne Guards Rifle Division
33rd Guards Rifle Corps (Iosif Popov)
95th Guards Rifle Division
97th Guards Rifle Division
9th Airborne Guards Rifle Division
Independent 42nd Guards Rifle Division
Independent 10th Tank Corps

5th Guards Tank Army (Pavel Rotmistrov)


5th Guards Mechanized Corps
29th Tank Corps


5th Air Army (Sergei Goriunov)
7th Mixed Air Corps
8th Mixed Air Corps
3rd Fighter Air Corps

7th Fighter Air Corps
